662304135922 Surface mount male header with 4 positions, 3.00mm pitch, shrouded with locking ramp. Rated for 5A and 250V.
Mfr Part #:

662304135922

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
Surface mount male header with 4 positions, 3.00mm pitch, shrouded with locking ramp. Rated for 5A and 250V.
✓ Total Stock: 266 pcs
$ Price Range: $2.51 - $4.19

662304135922 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
266 pcs
On Request
266 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

662304135922 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Connector Type
Contact Finish
Contact Material
Contact Resistance
Contact Shape
Contact Type
Current Rating
Current Rating (Amps)
Dielectric Withstanding Voltage
Fastening Type
Features
Halogen Free
Industrial Grade
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Material Flammability Rating
Medical Grade
Military Grade
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
SVHC Present
Shrouding
Style
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

662304135922 Description

Short technical summary and product information.

The Würth Elektronik 662304135922 is a 4-position single row male header with a 3.00mm pitch, designed for surface mount applications. It features a shrouded 4-wall design with a locking ramp for secure mating with cable assemblies. The header is rated for 5A current and 250V voltage, with an operating temperature range of -40°C to 105°C.



Constructed with a Liquid Crystal Polymer (LCP) insulator rated UL94 V-0 and copper alloy contacts with tin plating, this connector offers 25 mating cycles. It includes board lock and pick-and-place features for automated assembly. The contact resistance is 10 mΩ max, and insulation resistance is >1000 MΩ.



Packaged in tape and reel with cap, this header is suitable for board-to-cable/wire connections in various electronic devices. It is RoHS compliant and lead-free.

662304135922 Quick Information

Product Type: Header, Male Pins
Series: WR-MPC3
Canonical Name: Würth Elektronik 662304135922 - 3.00mm Pitch Single Row 4-Position SMT Male Header with Locking Ramp
Subcategory: Male Pins

662304135922 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

662304135922 Estimated Pricing

Qty Low High
1+ $4.19 $4.19
100+ $3.49 $3.49
250+ $3.07 $3.07
500+ $2.51 $2.51

Estimated market price range - modelled values for guidance only, not live distributor offers.

662304135922 Features

  • 4-position single row SMT header.
  • 3.00mm pitch for compact designs.
  • Shrouded 4-wall with locking ramp.
  • Rated for 5A and 250V.
  • RoHS compliant and lead-free.

662304135922 Applications

  • Used in board-to-cable connections.
  • Suitable for industrial control systems.
  • Ideal for consumer electronics wiring.
  • Applicable in automotive interior modules.

662304135922 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 662304135922 have?

4 positions.

What is the pitch of this header?

3.00mm.

What is the current rating?

5A.

What is the voltage rating?

250V.

What is the mounting type?

Surface Mount.

What is the operating temperature range?

-40°C to 105°C.

Is this header RoHS compliant?

Yes, RoHS compliant.
