| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Würth Elektronik 662004235922 is a 4-position, dual row, 3.00mm pitch surface mount vertical header designed for board-to-cable/wire applications. It features a shrouded 4-wall design with a locking ramp fastening system for secure mating. The header uses stamped copper alloy contacts with a tin finish and is housed in a black liquid crystal polymer (LCP) insulator rated UL94 V-0.
Electrical ratings include a current rating of 5A, working voltage of 250V AC, contact resistance of 10 mOhm max, insulation resistance greater than 1000 MOhm, and a dielectric withstanding voltage of 1500V AC. The operating temperature range is -40°C to 105°C. The part is RoHS compliant and lead-free.
The header is packaged in a tube and is intended for surface mount soldering. It includes a board lock feature for additional mechanical retention. The part number 662004235922 corresponds to a 4-position configuration with all positions loaded.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.29 | $1.29 |
| 10+ | $1.27 | $1.27 |
| 50+ | $1.17 | $1.17 |
| 100+ | $1.02 | $1.02 |
| 504+ | $0.95 | $0.95 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 4 positions arranged in 2 rows, all positions loaded.
The pitch is 3.00mm.
The current rating is 5A.
The working voltage is 250V AC.
It is a surface mount (SMT) component with solder termination.
The operating temperature range is -40°C to 105°C.
Yes, it is RoHS3 compliant and lead-free.
