| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,271 pcs
|
2271 pcs | On Request | 21 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating | |
| Withstanding Voltage |
The Würth Elektronik 66100811722 is an 8 position single row male pin header featuring a right angle through hole mounting style with a 2.54mm (0.100") pitch. The connector is shrouded with a locking ramp for secure mating in board-to-cable/wire applications. Electrical ratings include 3A current and 50VAC voltage. The insulator is made of Polyamide (PA46), Nylon 4/6 with UL94 V-0 flammability rating, colored black. Contacts are phosphor bronze with tin plating, capable of 25 mating cycles. Operating temperature ranges from -40°C to +125°C. The header supports JEDEC lead free wave soldering and is packaged in a box. Compliance includes RoHS3 and lead-free requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
| 50+ | $1.12 | $1.12 |
| 100+ | $1.00 | $1.00 |
| 500+ | $0.80 | $0.80 |
| 1,000+ | $0.72 | $0.72 |
| 2,000+ | $0.67 | $0.67 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
8 positions in a single row.
2.54mm (0.100").
Rated for 3A current and 50VAC voltage.
Through hole, right angle with solder termination.
Yes, 2-wall shrouding with a locking ramp.
-40°C to +125°C.
Polyamide (PA46) Nylon 4/6 with UL94 V-0 rating.
