66089-0830 The Anaren Microwave 66089-0830 is an 866 MHz RF antenna. It features a straight whip design with a U.FL connector mount and provides a typical gain of 3dBi.
Mfr Part #:

66089-0830

Available from 1 distributors
Mfr Name: Anaren Microwave Inc.
Anaren Microwave Inc.
The Anaren Microwave 66089-0830 is an 866 MHz RF antenna. It features a straight whip design with a U.FL connector mount and provides a typical gain of 3dBi.
✓ Total Stock: 100 pcs
$ Price Range: $0.99

66089-0830 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Seba Components ✓
Non-Authorised Inventory information
100 pcs
On Request
100 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

66089-0830 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Bandwidth
Frequency
Height
Mounting Type
Number of Bands
Termination Style
View Similar Products (0)

66089-0830 Description

Short technical summary and product information.

The Anaren Microwave 66089-0830 is a straight whip RF antenna operating at 866 MHz. This embedded antenna is designed for wireless applications and features a U.FL (UMCC), IPEX MHF1 connector mount.



Key electrical specifications include a nominal center frequency of 866 MHz with a bandwidth of 866 MHz. The antenna has an impedance of 50 Ohms and a maximum VSWR of 1.7. It offers a typical antenna gain of 3dBi, making it suitable for various RF communication systems.



Mechanically, the antenna has a maximum height of 116.00 mm (4.567 inches) and is supplied in a tray package. The mounting type is connector mount, and the termination style is U.FL.



This component is classified under the UHF frequency group (300MHz ~ 1GHz). It is listed with RoHS compliance and an MSL of 1 (Unlimited).

66089-0830 Quick Information

Product Type: RF Antenna
Series: 66089
Canonical Name: 866MHz Whip, Straight RF Antenna
Subcategory: RF Antenna

66089-0830 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

66089-0830 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

66089-0830 Features

  • 866 MHz center frequency operation.
  • 3dBi typical antenna gain.
  • 50 Ohm impedance with 1.7 VSWR.
  • U.FL connector mount termination.
  • Straight whip antenna design.

66089-0830 Applications

  • Suitable for 866 MHz UHF wireless communication systems.
  • Ideal for omnidirectional RF antenna applications.
  • Used in U.FL connector mounted antenna setups.
  • Applicable in RF signal transmission and reception.
  • Suitable for wireless sensor and IoT devices.

66089-0830 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the center frequency of the 66089-0830 RF antenna?

The center frequency is 866 MHz.

What is the typical antenna gain for the 66089-0830?

The typical antenna gain is 3 dBi.

What is the impedance of the 66089-0830 antenna?

The impedance is 50 Ohms.

What is the maximum VSWR for this antenna?

The maximum VSWR is 1.7.

What type of connector does the 66089-0830 use?

It uses a U.FL connector.

How is the 66089-0830 antenna mounted?

It is a connector mount type.

What is the Moisture Sensitivity Level (MSL) for this part?

The MSL is 1 (Unlimited).
