| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Locking Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Termination | |
| Voltage Rating |
The Amphenol ICC 65801-004LF is a 4-position FFC/FPC receptacle connector with a 2.54mm pitch. It features a zero insertion force (ZIF) design with a slide lock for secure cable retention. The connector supports FFC/FPC thicknesses of 0.30mm and 0.33mm. Termination is solder type, and mounting is free hanging (in-line). The housing is made of thermoplastic with a UL94 V-0 flammability rating. Contacts are copper nickel alloy with a tin finish. The operating temperature range is -65°C to 105°C, and the voltage rating is 500V. This connector is suitable for applications requiring reliable flat flexible cable interconnects in space-constrained electronic assemblies.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.22 | $1.22 |
| 10+ | $1.03 | $1.03 |
| 25+ | $0.97 | $0.97 |
| 50+ | $0.92 | $0.92 |
| 100+ | $0.88 | $0.88 |
| 250+ | $0.82 | $0.82 |
| 500+ | $0.78 | $0.78 |
| 1,344+ | $0.73 | $0.73 |
| 2,688+ | $0.70 | $0.70 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions.
2.54mm (0.100").
500V.
Free hanging (in-line).
-65°C to 105°C.
Slide lock.
UL94 V-0.
