| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
122 pcs
|
122 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Connector Usage | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Layout, Typical | |
| Lead Style | |
| Mounting Type | |
| Number of Columns | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Storage Temperature | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The TE Connectivity 6469074-1 is a high speed backplane connector designed for dense signal routing in telecommunications and data networking equipment. It features 120 positions arranged in 8 rows and 10 columns on a 2.50mm pitch, with 80 single signal contacts and 40 ground contacts for improved signal integrity.
The connector uses gold-plated contacts with 30µin thickness for reliable low-resistance connections. It is terminated via press-fit technology, allowing solderless through-hole mounting that reduces assembly time and improves reliability.
The 6469074-1 is listed as RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited). It is a through-hole, press-fit connector suitable for high speed backplane applications requiring high contact density and robust mechanical performance.
| Qty | Low | High |
|---|---|---|
| 1+ | $25.48 | $25.48 |
| 10+ | $18.32 | $18.32 |
| 20+ | $17.47 | $17.47 |
| 60+ | $16.93 | $16.93 |
| 100+ | $16.36 | $16.36 |
| 260+ | $15.23 | $15.23 |
| 500+ | $15.16 | $15.16 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
120 positions, all loaded.
2.50mm (0.098 inches).
Through hole with press-fit termination.
Gold, 30.0µin thick.
8 rows and 10 columns.
80 single signal contacts and 40 ground contacts.
It is listed as RoHS3 compliant, though unverified.
