| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,247 pcs
|
1247 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
137 pcs
|
137 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| China RoHS | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| ELV | |
| Features | |
| Halogen Free | |
| LED Color | |
| Mounting Type | |
| Number of Ports | |
| Number of Positions | |
| Number of Rows | |
| Orientation | |
| Ratings | |
| Shielding | |
| Solder Process Capability | |
| Tab Direction | |
| Tape & Reel | |
| Termination |
The TE Connectivity 6368150-1 is a single-port modular jack designed for 8p8c (RJ45, Ethernet) connectors. It features a shielded construction to reduce electromagnetic interference and is rated for Cat5 applications. The connector is mounted through hole with a vertical orientation and uses solder termination for reliable connections.
The jack includes a board guide feature for easier alignment during assembly and has gold-plated phosphor bronze contacts for durability and signal integrity. The tab direction is user selectable, offering flexibility in cable orientation. The component is wave solder capable to 265°C, making it suitable for standard wave soldering processes.
This part is compliant with EU RoHS, EU ELV, China RoHS 2, and is low halogen (Br, Cl, F, I < 900 ppm per homogenous material, BFR/CFR/PVC free). It does not contain REACH SVHC as per the current ECHA candidate list.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.67 | $4.67 |
| 10+ | $4.33 | $4.33 |
| 29+ | $3.48 | $3.48 |
| 58+ | $3.43 | $3.43 |
| 116+ | $3.30 | $3.30 |
| 261+ | $3.27 | $3.27 |
| 522+ | $3.18 | $3.18 |
| 870+ | $2.98 | $2.98 |
| 2,610+ | $2.78 | $2.78 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It is a modular jack with 8p8c (RJ45, Ethernet) configuration, 1 port, 1 row.
Through hole mounting with vertical orientation and solder termination.
Yes, it is shielded.
Gold contact finish on phosphor bronze contact material.
User selectable.
Wave solder capable to 265°C.
RoHS compliant (EU RoHS Directive 2011/65/EU incl. Delegated Directive 2015/863/EU), REACH compliant (does not contain REACH SVHC), ELV compliant, China RoHS 2 compliant, and low halogen (BFR/CFR/PVC free).
