| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7 pcs
|
7 pcs | On Request | 7 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Würth Elektronik 62403221622 is a 32-position, dual row male pin header with a 2.00mm pitch, designed for board-to-cable/wire applications. It features a vertical orientation with a shrouded 4-wall housing, ensuring secure mating and protection of contacts. The connector uses through-hole mounting and supports both press-fit and solder termination.
The header is rated for 3A current and 250V AC working voltage, with an operating temperature range of -25°C to 85°C. It is built with copper alloy contacts plated with tin, providing reliable conductivity, and a PBT insulator with UL94 V-0 flammability rating. The design includes a latch holder fastening system and board guide features for alignment.
Packaged in tubes and compatible with JEDEC lead-free wave soldering, this connector is RoHS compliant and lead-free. It is suitable for general electronic equipment where a reliable, high-density interconnection is required.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.00 | $7.00 |
| 10+ | $6.05 | $6.05 |
| 100+ | $5.52 | $5.52 |
| 250+ | $4.45 | $4.45 |
| 500+ | $4.10 | $4.10 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.00mm.
It has 32 positions.
The current rating is 3A.
The voltage rating is 250V AC.
Through hole mounting.
Yes, it is RoHS compliant.
-25°C to 85°C.
