| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
816 pcs
|
816 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Würth Elektronik 61900419521 is a 4-position, single-row, right-angle through-hole male pin header with a 2.54mm (0.100") pitch. It features a shrouded 1-wall design with a friction lock fastening system, providing secure mating with compatible cable housings. The header is rated for 3A of current and 250V AC working voltage, with an operating temperature range of -40°C to 105°C. Electrical characteristics include an insulator resistance of >1000 MΩ, dielectric withstanding voltage of 1000V AC, and contact resistance of 20 mΩ max.
The connector is built with a beige nylon 6/6 (PA66) insulator rated UL94 V-0. Contacts are made of copper alloy with a tin plating, and are rated for 25 mating cycles. The right-angle orientation and through-hole termination make it suitable for board-to-cable/wire applications. This part is packaged in a bag and is RoHS compliant and lead free.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.60 | $0.60 |
| 10+ | $0.54 | $0.54 |
| 25+ | $0.54 | $0.54 |
| 50+ | $0.51 | $0.51 |
| 100+ | $0.44 | $0.44 |
| 500+ | $0.42 | $0.42 |
| 1,000+ | $0.37 | $0.37 |
| 3,000+ | $0.37 | $0.37 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions, all loaded in a single row.
2.54mm (0.100").
3A
250V AC
Through hole, right angle.
Yes, it has a shrouded 1-wall design with friction lock.
-40°C to 105°C.
