618025231121 D-Sub receptacle with 25 female contacts in a 2-row right angle through-hole configuration. Features gold-plated contacts, nickel-plated steel shell, and board lock for secure mounting.
Mfr Part #:

618025231121

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
D-Sub receptacle with 25 female contacts in a 2-row right angle through-hole configuration. Features gold-plated contacts, nickel-plated steel shell, and board lock for secure mounting.
✓ Total Stock: 57 pcs
$ Price Range: $3.01 - $5.35

618025231121 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
57 pcs
On Request
57 pcs On Request 1 On Request On Request 13+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

618025231121 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Backset Spacing
Connector Style
Connector Type
Contact Finish
Contact Material
Contact Resistance
Contact Type
Current Rating
Current Rating (Amps)
Dielectric Withstanding Voltage
Features
Flange Feature
Industrial Grade
Insulation Resistance
Insulator Material
Lead Style
Material Flammability Rating
Medical Grade
Military Grade
Mounting Type
Number of Positions
Number of Rows
Operating Temperature
SVHC Present
Shell Material, Finish
Shell Size, Connector Layout
Tape & Reel
Termination
Working Voltage
View Similar Products (0)

618025231121 Description

Short technical summary and product information.

This is a D-Sub receptacle connector from Würth Elektronik, part number 618025231121. It features 25 female socket contacts arranged in 2 rows, with a DB-25 shell size. The connector is designed for right-angle through-hole mounting and solder termination.



Electrical specifications include a current rating of 3A per contact, working voltage of 125V AC, insulation resistance greater than 5000 MΩ, and dielectric withstanding voltage of 1000V AC. Contact resistance is 30 mΩ maximum. The operating temperature range is -55°C to 105°C.



The insulator is made of PBT with UL94 V-0 flammability rating. Contacts are copper alloy with gold plating. The shell is steel with nickel plating. The connector includes a board lock feature and female screwlock (4-40) on the mating side. Backset spacing is 8.08 mm.



Packaging is in trays. The connector is RoHS and lead-free compliant. It is suitable for general electronics applications requiring reliable D-Sub connections.

618025231121 Quick Information

Product Type: D-Sub Connector Assembly
Series: WR-DSUB
Canonical Name: D-Sub Receptacle, Female Sockets, 25 Position, 2 Row, Through Hole, Right Angle, Solder Termination
Subcategory: Standard D-Sub

618025231121 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead Free

618025231121 Estimated Pricing

Qty Low High
1+ $5.35 $5.35
10+ $5.08 $5.08
50+ $4.51 $4.51
100+ $3.93 $3.93
250+ $3.37 $3.37
500+ $3.01 $3.01

Estimated market price range - modelled values for guidance only, not live distributor offers.

618025231121 Features

  • 25-position D-Sub receptacle with female contacts.
  • Right-angle through-hole mounting for space savings.
  • Gold-plated contacts for reliable signal transmission.
  • Rated for 3A current and 125V AC voltage.
  • RoHS compliant and lead-free soldering compatible.

618025231121 Applications

  • Ideal for industrial control and automation systems.
  • Used in data communication and peripheral connections.
  • Suitable for test and measurement equipment.
  • Common in computer and networking hardware.

618025231121 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does this connector have?

25 positions.

What is the current rating?

3A per contact.

What is the voltage rating?

125V AC.

What is the mounting type?

Through hole, right angle.

What is the operating temperature range?

-55°C to 105°C.

What is the contact finish?

Gold.

Is this connector RoHS compliant?

Yes, RoHS3 compliant.
