| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Types | |
| Center Contact Material | |
| Connector Type | |
| Contact Finish | |
| Failure Rate | |
| Ferrule Material | |
| Insulator Material | |
| Mounting Type | |
| Outer Contact Material | |
| Tape & Reel | |
| Weight | |
| characteristic_impedance (@ For FILECA F 1709/8 cable, RG 179 cable) | |
| characteristic_impedance (@ For RG 316 cable, FILECA F 1709/6 cable, RG 188 cable) | |
| characteristic_impedance (@ For contact) |
This is a Radiall EPX series size 15 pin coax contact designed for use with RG316, RG188, RG179, FILECA F1709/6 and FILECA F1709/8 cables. The contact has a characteristic impedance of 23 Ω for the contact itself, 50 Ω when used with RG316, FILECA F1709/6, or RG188 cables, and 75 Ω when used with FILECA F1709/8 or RG179 cables.
The outer contact, center contact, and ferrule are made of copper alloy with gold over nickel plating. The insulator is PTFE. The contact is crimp mounted and has an estimated weight of 0.45 g. This part is RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $54.94 | $54.94 |
| 10+ | $49.76 | $49.76 |
| 25+ | $48.63 | $48.63 |
| 50+ | $47.77 | $47.77 |
| 100+ | $46.34 | $46.34 |
| 250+ | $46.32 | $46.32 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The contact itself has 23 Ω impedance. When used with RG316, FILECA F1709/6, or RG188 cables it is 50 Ω. With FILECA F1709/8 or RG179 cables it is 75 Ω.
RG316, FILECA F1709/8, FILECA F1709/6, RG188, and RG179 cables.
Crimp mount.
Outer contact, center contact, and ferrule are copper alloy with gold over nickel plating. Insulator is PTFE.
0.45 g nominal.
