| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Würth Elektronik 61300821021 is a 8-position, 2-row, 2.54mm pitch right-angle male pin header designed for board-to-board or cable applications. The header features square, gold-plated copper alloy contacts with stamped construction, housed in a black polyamide (PA6T) insulator rated UL94 V-0. Electrical ratings include 3A current, 250V AC voltage, 20 mOhm max contact resistance, and >1000 MOhm insulation resistance. The operating temperature range is -40°C to 105°C. This unshrouded, push-pull fastening header is through-hole mounted with right-angle orientation and solder termination. It is RoHS compliant and lead-free, with a quality class of 3 per CECC 75 301-802. Packaging is in bags.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
| 10+ | $0.64 | $0.64 |
| 25+ | $0.53 | $0.53 |
| 50+ | $0.44 | $0.44 |
| 100+ | $0.40 | $0.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
8 positions in 2 rows.
2.54mm.
3A.
250V.
Through-hole, right angle.
-40°C to 105°C.
Gold.
