The 612N/2GHH is a DC brushless tubeaxial fan from ebm-papst. It operates at 12VDC with a rated power consumption of 3.1W and draws 0.258A. The fan delivers an airflow of 33.0 CFM (0.924 m³/min) with a static pressure of 113.0 Pa (0.454 in H2O) at a speed of 6350 RPM. Noise level is rated at 16.0 dB(A).
The fan features a 60mm x 60mm square frame with a depth of 25.4mm and weighs 86.18g. It uses a Sintec bearing and includes three wire leads for termination. Built-in features include auto restart, locked rotor protection, and a speed sensor (tach) output. The operating temperature range is -20 to 70°C.
The fan is approved by CE, CSA, EAC, UL, and VDE. It is intended for applications requiring reliable cooling in a compact package.
The operating voltage is 12VDC.
The operating temperature range is -20 to 70°C.
The fan has a square frame of 60mm x 60mm and a depth of 25.4mm.
The RoHS status is listed as RoHS3 compliant, but this is unverified and should be confirmed with the manufacturer.
The fan provides 33.0 CFM (0.924 m³/min) of airflow.
The noise level is 16.0 dB(A).
Yes, the fan includes a speed sensor (tach) output.
