| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
31 pcs
|
31 pcs | On Request | 31 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Cable Termination | |
| Color | |
| Conflict Minerals | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Plating | |
| Contact Resistance | |
| Contact Type | |
| Current Rating | |
| Dielectric Withstanding Voltage | |
| Features | |
| Flammability Rating | |
| Industrial Grade | |
| Insulation Resistance | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| Wire Type | |
| Working Voltage |
The Würth Elektronik 61205025821 is a 50-position male pin header connector designed for insulation displacement connection (IDC) to ribbon cable. It features a 2.54mm pitch with two rows and a row spacing of 0.100 in (2.54 mm). The connector is free hanging (in-line) and comes in a gray PBT insulator with a UL94 V-0 flammability rating.
Electrical ratings include a maximum current of 1 A and a working voltage of 250 V AC. The contact resistance is 20 mohm max, insulation resistance is greater than 1000 Mohm, and dielectric withstanding voltage is 500 V AC/min. Contacts are made of copper alloy with selective gold plating.
Operating temperature range is -40°C to 125°C. The connector is RoHS compliant and lead free. Packaging is tray. The feed-through feature allows pass-through wiring.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.16 | $7.16 |
| 10+ | $6.88 | $6.88 |
| 30+ | $6.04 | $6.04 |
| 60+ | $5.22 | $5.22 |
| 120+ | $4.38 | $4.38 |
| 240+ | $3.91 | $3.91 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 positions (2 rows of 25).
2.54 mm (0.100 inch).
1 A maximum.
250 V AC.
Free hanging (in-line).
-40°C to 125°C.
UL94 V-0.
