Mfr Part #:

61205022121

This is a 50-position, 2.54mm pitch, right-angle male pin header from Würth Elektronik. It features a shrouded 4-wall design with gold-plated contacts and a 3A current rating.

✓ Total Stock: 33 pcs

$ Price Range: $2.19 - $4.01

61205022121 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Fe Components ✓ Non-Authorised Inventory information	33 pcs On Request	33 pcs	On Request	11	On Request	On Request	On Request	On Request	On Request

61205022121 Description

Short technical summary and product information.

The Würth Elektronik 61205022121 is a 50-position, dual-row, right-angle male pin header with a 2.54mm pitch and row spacing. It uses a shrouded 4-wall housing with short latch lock/eject hooks for secure mating in board-to-cable/wire applications. Contacts are made of copper alloy with a square shape and gold plating, ensuring low contact resistance of 20 mΩ max. The insulation is black PBT rated UL94 V-0, with an insulation height of 8.30mm. Electrical ratings include 3A current and 250V AC voltage, with an operating temperature range of -40°C to 125°C. The connector is RoHS and lead-free compliant, certified under UL standard E323964, and meets quality class 3 per CECC 75 301-802. It is packaged in trays.

61205022121 Quick Information

Product Type: Header, Male Pins

Series: WR-BHD

Canonical Name: Würth Elektronik 61205022121, 50 Position, 2.54mm Pitch, Right Angle, Shrouded Header, Male Pins

Subcategory: Box Header

61205022121 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

61205022121 Estimated Pricing

Qty	Low	High
1+	$4.01	$4.01
10+	$3.85	$3.85
70+	$3.38	$3.38
140+	$2.92	$2.92
280+	$2.45	$2.45
560+	$2.19	$2.19

Estimated market price range - modelled values for guidance only, not live distributor offers.

61205022121 Features

50 positions in dual-row configuration.
2.54mm pitch for compact designs.
Right-angle mounting for space-saving layouts.
Gold-plated contacts for corrosion resistance.
Shrouded housing with latch lock for secure connection.

61205022121 Applications

Ideal for board-to-cable interconnections.
Used in industrial control systems.
Suitable for data communication equipment.
Common in automotive electronics.
Applicable in consumer electronics.

61205022121 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the number of positions?

50 positions, all loaded.

What is the pitch of this header?

2.54mm (0.100 inches).

What is the current rating?

3A maximum.

What is the voltage rating?

250V AC.

What is the mounting type?

Through hole, right angle.

What is the operating temperature range?

-40°C to 125°C.

Is this header RoHS compliant?

Yes, RoHS and lead-free compliant.

Category	Headers, Male Pins
Manufacturer Name	Würth Elektronik
Connector Type	Header
Contact Finish	Gold
Contact Length	5.70mm (0.224")
Contact Material	Copper Alloy
Contact Resistance	20 mΩ max
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3A
Dielectric Withstanding Voltage	500 VAC
Fastening Type	Latch Lock/Eject Hooks, Short
Features	Keying Slot
Halogen Free	Yes
Insulation Color	Black
Insulation Height	8.30mm (0.327")
Insulation Material	Polybutylene Terephthalate (PBT)
Lead Spacing	2.54 mm
Lead Style	Solder
Material Flammability Rating	UL94 V-0
Military Grade	No
Mounting Type	Through Hole, Right Angle
Number of Positions	50
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-40°C ~ 125°C
Pitch	2.54mm (0.100")
Row Spacing	0.100" (2.54mm)
SVHC Present	Not Present
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	250V
