The Würth Elektronik 61202021721 is a WR-BHD series male angled box header designed for board-to-cable/wire connections. It features 20 positions arranged in 2 rows with a 2.54mm pitch and 2.54mm row spacing. The connector is fully shrouded with a 4-wall design and includes a keying slot for polarization.
Electrical ratings include a current rating of 3A and a voltage rating of 250V. Contact resistance is 20 mΩ maximum, insulation resistance is 1000 MΩ minimum, and the connector withstands 500V AC for 1 minute. The operating temperature range is -40°C to +105°C.
The header uses square male pins made of copper alloy with gold contact finish. The insulator is black polybutylene terephthalate (PBT) rated UL94 V-0. Mounting is through hole right angle with solder termination. The connector is rated for 30 mating cycles.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.05 | $1.05 |
| 10+ | $1.04 | $1.04 |
| 50+ | $0.95 | $0.95 |
| 160+ | $0.86 | $0.86 |
| 320+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100") with a row spacing of 2.54mm.
The current rating is 3A.
The voltage rating is 250V.
Through hole, right angle mounting with solder termination.
-40°C to +105°C.
Yes, it is RoHS compliant per 2011/65/EU & 2015/863.
Copper alloy contacts with gold finish.
