| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
27 pcs
|
27 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Würth Elektronik 61002421121 is a 24-position, 2-row surface mount pin header with a 2.54mm pitch and row spacing. The connector features unshrouded male square pins with gold-plated copper alloy contacts, ensuring reliable signal integrity and corrosion resistance. The insulation is made of black PA6T (Nylon 6T) with a UL94 V-0 flammability rating, suitable for high-temperature environments.
Electrical ratings include 3A current capacity and 250V AC working voltage, with a maximum contact resistance of 20 mOhm and minimum insulator resistance of 1000 MOhm. The dielectric withstanding voltage is 500V AC. The operating temperature range spans -40°C to 125°C, making it suitable for a wide variety of applications.
This header is designed for board-to-board or cable-to-board connections and uses a push-pull fastening mechanism. It is packaged in a tube and is RoHS3 compliant and lead-free. The part is certified to JEDEC lead-free reflow soldering standards and meets quality class 3 per CECC 75 301-802.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.74 | $3.74 |
| 10+ | $2.65 | $2.65 |
| 40+ | $2.21 | $2.21 |
| 80+ | $2.01 | $2.01 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
24 positions, all loaded.
2.54mm (0.100 inches).
3A.
250V AC.
Surface mount with solder termination.
-40°C to 125°C.
Gold plating on copper alloy contacts.
