61000618221 6-position, 2.54mm pitch SMT pin header from Würth Elektronik. Features gold-plated contacts, UL94 V-0 rated insulation, and operating temperature range -40°C to 125°C.
Mfr Part #:

61000618221

Available from 2 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
6-position, 2.54mm pitch SMT pin header from Würth Elektronik. Features gold-plated contacts, UL94 V-0 rated insulation, and operating temperature range -40°C to 125°C.
✓ Total Stock: 78 pcs
$ Price Range: $0.74 - $1.37

61000618221 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
58 pcs
On Request
58 pcs On Request 1 On Request On Request On Request On Request On Request
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
20 pcs
On Request
20 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

61000618221 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Resistance
Contact Shape
Contact Type
Current Rating (Amps)
Dielectric Withstanding Voltage
Fastening Type
Halogen Free
Industrial Grade
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Medical Grade
Military Grade
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
SVHC Present
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

61000618221 Description

Short technical summary and product information.

The Würth Elektronik 61000618221 is a 6-position, single row, unshrouded pin header designed for surface mount soldering. With a pitch of 2.54mm, it is suitable for board-to-board or cable connections. The header features male square pins with gold plating over copper alloy, ensuring reliable contact and corrosion resistance. The insulator is made of black PA6T nylon with UL94 V-0 flammability rating, providing high safety in demanding applications. Electrical ratings include 3A current and 250VAC voltage, with contact resistance of 20mOhm max and insulator resistance over 1000MOhm. The dielectric withstanding voltage is 500VAC. The component operates from -40°C to 125°C, making it suitable for a wide range of environments. It is RoHS compliant and lead-free, and meets JEDEC lead-free reflow soldering requirements. The packaging is tube.

61000618221 Quick Information

Product Type: Pin Header
Series: WR-PHD
Canonical Name: Würth Elektronik 61000618221 — 6 Position, 2.54mm Pitch, Single Row, Unshrouded, SMT Pin Header
Subcategory: Unshrouded Pin Header

61000618221 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead Free

61000618221 Estimated Pricing

Qty Low High
1+ $1.37 $1.37
10+ $1.17 $1.17
41+ $0.97 $0.97
82+ $0.81 $0.81
164+ $0.74 $0.74

Estimated market price range - modelled values for guidance only, not live distributor offers.

61000618221 Features

  • 6-position single row SMT pin header.
  • 2.54mm pitch with gold-plated contacts.
  • Rated for 3A current and 250V voltage.
  • UL94 V-0 flammability rated PA6T insulator.
  • Operating temperature range -40°C to 125°C.

61000618221 Applications

  • Ideal for board-to-board interconnect applications.
  • Used for cable-to-board connections in general electronics.
  • Suitable for surface mount assembly processes.

61000618221 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 61000618221 header have?

6 positions.

What is the pitch of this Würth Elektronik header?

2.54mm.

What is the current rating of the 61000618221?

3A.

What is the voltage rating of this header?

250VAC.

What is the mounting type of the 61000618221?

Surface Mount.

What is the operating temperature range?

-40°C to 125°C.

Is the 61000618221 RoHS compliant?

Yes, RoHS3 compliant and lead-free.
