| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Flange Feature | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Size, Connector Layout | |
| Termination |
The Harting 60010685102 is a D-Sub connector assembly designed as a receptacle with 68 female socket contacts. It features a D-Type connector style with 2 rows and a shell size layout of 0.050 inch pitch by 0.100 inch row spacing, suitable for high-density signal applications. The connector is mounted via through hole termination and secured with a flange that includes M2.5 threaded inserts and latchblocks.
This connector is rated for a current of 1A per contact and is intended for signal-level circuits. The through hole design provides reliable mechanical attachment to the PCB, making it suitable for applications where vibration resistance and secure mating are required. The contacts are solder terminated, ensuring a robust electrical connection.
As a D-Sub receptacle, it is compatible with standard D-Sub plug connectors and is commonly used in industrial, data communication, and instrumentation systems. The part is listed as RoHS3 compliant, though this compliance status is unverified. No datasheet or manufacturer page content is available for further detail.
This D-Sub receptacle has 68 positions.
The connector has a 0.050 inch pitch and 0.100 inch row to row spacing.
The connector is rated for 1A per contact.
The connector is designed for through hole mounting.
The contacts are terminated by soldering.
The connector has 2 rows of contacts.
The connector style is D-Type.
