| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
399 pcs
|
399 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
224 pcs
|
224 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
This is a high-density connector from TE Connectivity, part number 6-104549-0. It is a 100-position header with male pin contacts arranged in 2 rows at 1.27mm pitch, ideal for board-to-board or cable applications. The connector features a shrouded 4-wall design with latch holder for secure mating.
Key specifications include a row spacing of 0.100" (2.54mm), contact length of 3.18mm, and insulation height of 11.05mm. Contacts are made of copper alloy with tin finish (0.76µm). The housing is black polyphthalamide (PPA) with UL94 V-0 flammability rating. Operating temperature range is -65°C to 105°C, and voltage rating is 30VAC.
The connector is surface mount with solder termination. It includes a board lock feature for secure attachment. All 100 positions are loaded. The insulation material is PPA, providing good thermal and mechanical properties.
| Qty | Low | High |
|---|---|---|
| 1+ | $38.75 | $38.75 |
| 14+ | $32.17 | $32.17 |
| 105+ | $27.91 | $27.91 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
100 positions, 2 rows, all loaded.
1.27mm (0.050")
30VAC
Surface mount with solder termination.
-65°C to 105°C
Tin, 0.76µm thickness
Yes, it has a shrouded 4-wall design with latch holder.
