| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Current Rating | |
| Current Rating (Amps) | |
| Depth | |
| Halogen Free | |
| Height | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Standards | |
| Terminal Type | |
| Voltage Rating | |
| Width |
This Siemens SENTRON 5SY4 series miniature circuit breaker, part number 5SY4606-6, is a 4-pole device designed for reliable short-circuit protection in electrical infrastructure. It operates with a Type B tripping characteristic and has a rated AC voltage of 400V, with a significant breaking capacity of 10kA.
The breaker supports a wide range of conductor sizes, from 0.75 mm² to 35 mm² for solid and stranded conductors, and up to 25 mm² for finely stranded conductors with core end processing. It is designed for DIN rail mounting and features screw terminals for secure connections. The unit has a mechanical service life of typically 10,000 operating cycles and is rated for an ambient operating temperature range of -40°C to 70°C.
Additional features include neutral conductor switching, sealability, and the ability to install supplementary devices. It meets various international standards including IEC/EN 60898-1 and IEC/EN 60947-2, with approvals from CCC, CE, EAC, IMQ, RCM, UR, and VDE.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Siemens 5SY4606-6 circuit breaker has a current rating of 6A.
The rated AC voltage for the Siemens 5SY4606-6 is 400V.
The breaking capacity of the Siemens 5SY4606-6 is 10kA according to EN 60898.
The Siemens 5SY4606-6 is a 4-pole circuit breaker.
The tripping characteristic class for the Siemens 5SY4606-6 is Type B.
The Siemens 5SY4606-6 can operate in ambient temperatures from -40°C to 70°C.
Yes, the Siemens 5SY4606-6 is halogen-free.
