This Siemens 5SJ4202-7HG41 is a 2-pole miniature circuit breaker from the 5SJ4 series. It features a C-trip characteristic and a rated current of 2A, suitable for various electrical protection applications.
The breaker operates at a rated voltage of 240V AC and has a switching capacity of 10kA according to EN 60898 and 15kA according to IEC 60947-2. It is designed for mechanical engineering and industrial applications.
With a width of 36mm and a depth of 70mm, it fits standard DIN rail mounting. The breaker also offers features like touch protection and is halogen-free, contributing to safety and environmental considerations in installations.
The rated current for the Siemens 5SJ4202-7HG41 is 2A at 30°C and 40°C.
The operating voltage for the 5SJ4202-7HG41 is a maximum of 240V AC according to UL 489 and CSA C22.2 No. 5-02.
The Siemens 5SJ4202-7HG41 is a 2-pole miniature circuit breaker.
The tripping characteristic class for the 5SJ4202-7HG41 is C.
The short circuit breaking capacity at AC according to UL 1077 and CSA C22.2 No.235 is 14 kA.
The 5SJ4202-7HG41 uses DIN rail mounting.
