The Kyocera AVX 5AK220JABAI is a 22 pF, 100 V DC rated ceramic disc capacitor with a C0G/NP0 temperature coefficient. This Class I dielectric offers a dissipation factor of ≤1/CR + 0.07 (for CR ≤ 30 pF), ensuring low losses at 1.0 MHz. The insulation resistance is a minimum of 10 GΩ at 500 V, and the dielectric strength is 250 V DC.
The capacitor is housed in a through-hole radial disc package with straight leads and 5.00 mm lead spacing. The disc diameter is 5.00 mm and height is 4.00 mm. It operates over a temperature range of -30°C to 85°C.
Designed for general purpose applications, its stable C0G/NP0 characteristics make it suitable for timing circuits, resonant circuits, and other precision applications where temperature stability is critical. The radial leaded format allows easy insertion into printed circuit boards and is compatible with automatic insertion equipment.
The capacitance is 22 pF.
The rated voltage is 100 V DC.
The temperature coefficient is C0G/NP0, which is a Class I temperature-stable dielectric.
The tolerance is ±5%.
The package is a through-hole radial leaded disc.
The operating temperature range is -30°C to 85°C.
For this 22 pF capacitor, the dissipation factor is ≤1/CR + 0.07, which equals ≤0.115 (11.5%) at 1.0 MHz.
