| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,204 pcs
|
1204 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Core Type | |
| Diameter | |
| Effective Area (Ae) mm² | |
| Effective Length (le) mm | |
| Effective Magnetic Volume (Ve) mm³ | |
| Finish | |
| Gap | |
| Height | |
| Inductance Factor (Al) | |
| Initial Permeability (µi) | |
| Material | |
| Tolerance |
The Fair-Rite Products Corp. 5943001821 is a toroid ferrite core designed for various magnetic applications. It is constructed from Material 43, known for its specific magnetic properties.
Key specifications include an initial permeability (µi) of 800, an effective magnetic volume (Ve) of 1420 mm³, and an effective area (Ae) of 26.2 mm². The core has an effective length (le) of 54 mm and an inductance factor (Al) of 485 nH. The diameter is 23.00mm (0.906 inches) and the height is 7.11mm (0.280 inches). This core is supplied ungapped and features a plastic coating for finish.
The tolerance for this component is -25%, +20%. It is classified under the Ferrite Cores category and is suitable for applications requiring specific inductance and magnetic flux characteristics.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The core type is Toroid.
The core is made of Material 43.
The initial permeability (µi) is 800.
The diameter is 23.00mm (0.906 inches) and the height is 7.11mm (0.280 inches).
The inductance factor (Al) is 485 nH.
No, the core is ungapped.
