577202B00000G Aluminum heat sink for TO-220 packages with bolt-on mounting. Features black anodized finish, 24.4°C/W natural convection thermal resistance, and compact 19.05mm length.
Mfr Part #:

577202B00000G

Available from 2 distributors
Mfr Name: Aavid, Thermal Division of Boyd Corporation
Aavid, Thermal Division of Boyd Corporation
Aluminum heat sink for TO-220 packages with bolt-on mounting. Features black anodized finish, 24.4°C/W natural convection thermal resistance, and compact 19.05mm length.
✓ Total Stock: 21,008 pcs
$ Price Range: $0.35 - $0.56

577202B00000G Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
AA2DE ✓
Non-Authorised Inventory information
20,000 pcs
On Request
20000 pcs On Request 1 On Request On Request On Request On Request On Request
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
1,008 pcs
On Request
1008 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

577202B00000G Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Attachment Method
Fin Height
Length
Material
Material Finish
Mounting Type
Package Cooled
Power Dissipation @ Temperature Rise
Shape
Tape & Reel
Thermal Resistance @ Forced Air Flow
Thermal Resistance @ Natural
Type
Width
View Similar Products (0)

577202B00000G Description

Short technical summary and product information.

The 577202B00000G is a board level heat sink designed for cooling TO-220 semiconductor packages. It is constructed from aluminum with a black anodized material finish, providing corrosion resistance and improved thermal emissivity. The heat sink has a rectangular shape with fins, measuring 19.05mm in length, 13.21mm in width, and a fin height of 12.70mm (0.500"). Attachment is via bolt-on mounting, making it suitable for permanent or semi-permanent installation.



Thermal performance is specified at 24.40°C/W under natural convection and 10.00°C/W at 200 LFM forced air flow, demonstrating significant improvement with active cooling. The heat sink can dissipate up to 1.5W at a 40°C temperature rise. This makes it appropriate for low-to-moderate power applications where TO-220 devices require thermal management in confined spaces.

577202B00000G Quick Information

Product Type: Heat Sink
Canonical Name: Board Level Heat Sink for TO-220, Rectangular with Fins, Black Anodized Aluminum, 19.05mm Length
Subcategory: Board Level Heat Sinks

577202B00000G Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

577202B00000G Estimated Pricing

Qty Low High
1+ $0.56 $0.56
10+ $0.50 $0.50
25+ $0.47 $0.47
50+ $0.45 $0.45
100+ $0.44 $0.44
250+ $0.42 $0.42
500+ $0.40 $0.40
1,000+ $0.38 $0.38
5,000+ $0.35 $0.35

Estimated market price range - modelled values for guidance only, not live distributor offers.

577202B00000G Features

  • Aluminum construction with black anodized finish.
  • Designed for TO-220 semiconductor packages.
  • Bolt-on attachment for secure mounting.
  • Thermal resistance 24.4°C/W natural convection.
  • Dissipates 1.5W at 40°C temperature rise.

577202B00000G Applications

  • Cools TO-220 regulators and transistors.
  • Suitable for low-power power supplies.
  • Used in industrial control circuits.
  • Compact design for PCB-level thermal management.
  • Works with forced air for improved performance.

577202B00000G FAQs

7 frequently asked questions generated from this part’s specifications.
What package is this heat sink designed for?

It is designed for the TO-220 package.

What is the thermal resistance of this heat sink?

The thermal resistance is 24.40°C/W under natural convection and 10.00°C/W at 200 LFM forced air flow.

What is the power dissipation capability?

It can dissipate 1.5W at a 40°C temperature rise.

What material is the heat sink made of?

It is made of aluminum with a black anodized finish.

How is the heat sink attached?

It is attached via bolt-on mounting.

What are the dimensions of the heat sink?

Length is 19.05mm, width is 13.21mm, and fin height is 12.70mm (0.500").

Is this heat sink RoHS compliant?

RoHS status is listed as RoHS3 Compliant, but this data is unverified and low confidence.
