| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
300 pcs
|
300 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Amphenol ICC 57202-G52-20LF is a 40-position unshrouded header designed for board-to-board applications. It features a 2-row configuration with a 2.00mm pitch and 2.00mm row spacing, providing a compact interface for high-density designs. The header uses male pin contacts made of copper alloy with a tin finish (30µin thickness) for reliable conductivity and solderability. The square contact shape and 4.00mm contact length ensure secure mating. The housing is molded from black thermoplastic with a UL94 V-0 flammability rating, offering robust mechanical support and flame resistance. The surface mount termination allows for automated assembly, and the push-pull fastening type simplifies board separation. With a current rating of 2A (AC/DC) and a voltage rating of 200V (AC/DC), this connector is suitable for low-power signal and power interconnect applications. The unshrouded design facilitates easy access and cleaning, making it ideal for prototyping and production environments.
40 positions.
2.00mm (0.079in).
2A (AC/DC).
200V (AC/DC).
Surface Mount.
Tin with 30µin (0.76µm) thickness.
Thermoplastic, UL94 V-0.
