57202-G52-05LF The 57202-G52-05LF is a 10-position, 2-row, 2mm pitch unshrouded male pin header from Amphenol ICC. It features surface mount termination and is rated for 2A and 200V.
Mfr Part #:

57202-G52-05LF

Available from 1 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
The 57202-G52-05LF is a 10-position, 2-row, 2mm pitch unshrouded male pin header from Amphenol ICC. It features surface mount termination and is rated for 2A and 200V.
✓ Total Stock: 100 pcs
$ Price Range: $0.68

57202-G52-05LF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
100 pcs
On Request
100 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

57202-G52-05LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Row Spacing
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

57202-G52-05LF Description

Short technical summary and product information.

This part is an unshrouded male pin header connector from Amphenol ICC, designed for board-to-board applications. It has 10 positions arranged in 2 rows with a 2.00mm pitch and row spacing. The contacts are made of copper alloy with a tin finish (0.76µm thick) and are square in shape.



The connector is surface mount with solder termination. It is rated for a maximum current of 2A (AC/DC) and voltage of 200V (AC/DC). The insulation material is thermoplastic (UL94 V-0 rated) and colored black. The contact length is 4.00mm.



This header is unshrouded and uses a push-pull fastening type. It is suitable for dense PCB layouts where space is limited. The Moisture Sensitivity Level is 1 (unlimited) and it is RoHS and REACH compliant.

57202-G52-05LF Quick Information

Product Type: Male Pin Header
Series: 57202
Canonical Name: 2.00mm Pitch 10 Position 2 Row Surface Mount Header Male Pin Connector
Subcategory: Male Pins

57202-G52-05LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

57202-G52-05LF Estimated Pricing

Qty Low High
162+ $0.68 $0.68

Estimated market price range - modelled values for guidance only, not live distributor offers.

57202-G52-05LF Features

  • 10 positions in 2 rows at 2mm pitch.
  • Rated for 2A and 200V operation.
  • Surface mount with solder termination.
  • Unshrouded push-pull connector design.
  • Tin-plated copper alloy contacts.

57202-G52-05LF Applications

  • Ideal for board-to-board interconnections.
  • Used in compact electronic assemblies.
  • Suitable for low-power signal and power connections.

57202-G52-05LF FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

10

What is the pitch of this header?

2.00mm (0.079")

What is the current rating?

2A (AC/DC) maximum

What is the voltage rating?

200V (AC/DC) maximum

What is the mounting type?

Surface Mount

What is the contact finish?

Tin

How many rows does it have?

2
