| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
155 pcs
|
155 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
This is a surface mount header from Amphenol ICC featuring 8 positions arranged in 2 rows with a 2.00mm pitch. The male pins are square and tin-plated for good conductivity, with a contact finish thickness of 0.76µm. The header is unshrouded and uses a push-pull fastening mechanism, commonly used in board-to-board applications.
Electrical ratings: 2A current and 200V voltage (AC/DC). The insulation is black thermoplastic with UL94 V-0 flammability rating. The header is designed for surface mount soldering, suitable for automated assembly. All positions are loaded. The contact material is copper alloy.
Compliance: RoHS3 compliant, MSL level 1 (unlimited), REACH unaffected. Moisture sensitivity level is 1, allowing unlimited floor life. The component is suitable for a variety of electronic assemblies requiring a compact, low-profile interconnect.
8 positions.
2.00mm.
2A (AC/DC).
200V (AC/DC).
Surface mount.
No, it is unshrouded.
Tin.
