57102-G06-08LF Amphenol ICC 57102-G06-08LF is a 16-position, 2-row, 2.00mm pitch unshrouded male pin header with through-hole termination. It features tin-plated square contacts and a black thermoplastic insulator rated UL94 V-0.
Mfr Part #:

57102-G06-08LF

Available from 1 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
Amphenol ICC 57102-G06-08LF is a 16-position, 2-row, 2.00mm pitch unshrouded male pin header with through-hole termination. It features tin-plated square contacts and a black thermoplastic insulator rated UL94 V-0.
✓ Total Stock: 1 pcs

57102-G06-08LF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

57102-G06-08LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Overall Contact Length
Pitch
Row Spacing
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

57102-G06-08LF Description

Short technical summary and product information.

The 57102-G06-08LF is a 16-position unshrouded male pin header from Amphenol ICC, designed for board-to-board connections. It has a 2.00mm pitch and two rows, with all positions loaded.



The header is through-hole mounted with solder termination, making it suitable for permanent PCB connections. The square pins are made of copper alloy with a 30µin tin finish. The black thermoplastic insulator meets UL94 V-0 flammability rating.



Electrical ratings are 2A (AC/DC) current and 200V (AC/DC) voltage. The overall contact length is 8.00mm, with a mating length of 4.00mm above the insulator. The insulation height is 1.50mm.



This connector is suitable for various electronic applications requiring a compact dual-row header. Its unshrouded design allows for easy mating with female receptacles.

57102-G06-08LF Quick Information

Product Type: Header, Male Pins
Canonical Name: Amphenol ICC 57102-G06-08LF, 16 Position 2.00mm Pitch Unshrouded Header, Through Hole, Tin Contact Finish
Subcategory: Unshrouded Male Pin Header

57102-G06-08LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

57102-G06-08LF Features

  • 16 positions in dual row 2.00mm pitch.
  • Through-hole solder termination for secure PCB mounting.
  • Tin-plated square copper alloy contacts.
  • UL94 V-0 rated black thermoplastic insulator.
  • Rated for 2A current and 200V voltage.

57102-G06-08LF Applications

  • Board-to-board connection in compact electronic assemblies.
  • Used in industrial control and automation equipment.
  • Suitable for consumer electronics and data processing.
  • Ideal for prototyping and low-power interconnects.

57102-G06-08LF FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 57102-G06-08LF have?

16 positions, all loaded.

What is the pitch of this header?

2.00mm (0.079 inches).

What is the current rating?

2A (AC/DC).

What is the voltage rating?

200V (AC/DC).

What is the mounting type?

Through hole, with solder termination.

What is the contact finish?

Tin, 30µin thick.

What is the insulator flammability rating?

UL94 V-0.
