| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
156 pcs
|
156 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Configuration | |
| Current | |
| Lens Color Style | |
| Lens Size | |
| Lens Style | |
| Lens shape | |
| Millicandela Rating | |
| Mounting Type | |
| Viewing Angle | |
| Voltage Rating | |
| Wavelength |
This Dialight 5680202122F is a Quad Level LED Circuit Board Indicator (CBI) designed for through-hole, right-angle mounting. It features four individual green LEDs, each with a 3mm (T-1) lens size and a dome shape.
The indicator operates with a typical forward current of 2mA and a forward voltage of 1.9V. The luminous intensity is rated at 1.6mcd, with a wavelength of 565nm and a viewing angle of 60 degrees. The lens is tinted and diffused, providing a clear visual indication.
This component is suitable for various board-level indicator applications where space is limited and a right-angle orientation is required. Its robust construction and specific electrical characteristics make it a reliable choice for status indication on printed circuit boards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward current is 2mA.
The typical luminous intensity is 1.6mcd.
The typical forward voltage is 1.9V.
The wavelength is 565nm.
The viewing angle is 60 degrees.
It is mounted through hole at a right angle.
The lens size is 3mm (T-1) and the shape is a dome.
