| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,050 pcs
|
3050 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Configuration | |
| Current | |
| Lens Size | |
| Lens Style | |
| Lens Type | |
| Millicandela Rating | |
| Mounting Type | |
| Viewing Angle | |
| Voltage Rating | |
| Wavelength |
The Dialight 5663507 is a bi-color LED Circuit Board Indicator (CBI) designed for through-hole, right-angle mounting. This component features both Red and Green LEDs within a single package, allowing for versatile signaling.
Key electrical specifications include a typical forward current of 10mA. The forward voltage for the Green LED is 2.1V, and for the Red LED, it is 1.9V. The luminous intensity is rated at 4mcd for Green and 3.5mcd for Red, both at 10mA. The viewing angle is 100°, providing a wide illumination spread.
The LED has a diffused, rectangular lens measuring 5.00mm x 2.00mm. The CBI housing is designed with stand-offs to facilitate PCB cleaning. This component is suitable for applications requiring visual indication with multiple color options from a single indicator.
Compliance information indicates RoHS3 compliance, MSL 1, and REACH unaffected status. However, these compliance details are unverified.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The forward voltage is 2.1V for Green and 1.9V for Red, typically at 10mA.
The typical luminous intensity is 4mcd for Green and 3.5mcd for Red, both at 10mA.
The viewing angle is 100°.
The lens size is 5.00mm x 2.00mm.
It is mounted through hole at a right angle.
