| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Configuration | |
| Current | |
| Housing Flame Rating | |
| Housing Material | |
| LED Safety | |
| Lens Style | |
| Lens Type | |
| Millicandela Rating | |
| Mounting Type | |
| Oxygen Index | |
| Peak Wavelength | |
| Solderability | |
| Viewing Angle | |
| Voltage Rating | |
| Wavelength |
This Dialight 5660407F is a single red LED circuit board indicator designed for through-hole mounting at a right angle. It features a rectangular, flat-top lens that is diffused and tinted, measuring 5.00mm x 2.00mm. The LED operates with a typical forward voltage of 2V and a forward current of 20mA, emitting light at a peak wavelength of 635nm. The luminous intensity is rated at 7.4mcd with a wide viewing angle of 140°.
The housing is made of PBT material and is UL 94 V-0 rated for flame resistance. The LED is safe for direct viewing according to IEC 825-1 and EN-60825-1 standards. Solderability is per MIL-STD-202F, method 208F. The component is RoHS3 compliant and REACH unaffected, with an MSL of 1.
This indicator is suitable for applications requiring a reliable red light source on a printed circuit board, offering clear visual indication with its diffused and tinted lens.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage for the 5660407F LED is 2V at 20mA.
The peak wavelength for the 5660407F LED is 635nm.
The viewing angle for the 5660407F LED is 140°.
Yes, this part is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the 5660407F is 1 Unlimited.
