The 5646957-1 from TE Connectivity is a UPM (Universal Power Module) Expanded Pin Assembly header designed for backplane power applications. It is part of the Z-Pack 2mm HM connector series, utilizing the 2mm hard metric grid pattern. This header features 7 male blade power contacts arranged in a single row, with all positions loaded.
The connector is available in a gray housing and offers a right angle orientation with board edge, through-hole mounting. Termination is achieved via press-fit technology, ensuring a reliable solderless connection. A built-in board guide aids in alignment during assembly. The contacts are finished with gold or gold-palladium for enhanced conductivity and durability.
This product is compliant with RoHS3 and REACH unaffected, with an MSL of 1 (unlimited floor life). It is suitable for use in backplane power distribution systems where compact, high-density power connections are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $17.36 | $17.36 |
| 23+ | $13.91 | $13.91 |
| 46+ | $13.25 | $13.25 |
| 69+ | $12.88 | $12.88 |
| 115+ | $12.42 | $12.42 |
| 253+ | $11.75 | $11.75 |
| 506+ | $11.19 | $11.19 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The connector has 7 positions (power contacts) in a single row.
Board edge, through-hole, right angle mounting.
Press-fit termination.
Yes, it is RoHS3 compliant and REACH unaffected.
Z-Pack 2mm HM series, specifically the UPM Expanded Pin Assembly.
Gray.
It includes a board guide for alignment during mating.
