| Category | |
| Manufacturer Name | |
| Color | |
| Configuration | |
| Current | |
| Lens Size | |
| Lens Style | |
| Lens Type | |
| Millicandela Rating | |
| Mounting Type | |
| Viewing Angle | |
| Voltage Rating | |
| Wavelength |
This Dialight 5615501050 is a single, red LED circuit board indicator designed for through-hole mounting. It operates at a typical forward voltage of 2.2V and a forward current of 20mA, producing a luminous intensity of 125mcd. The LED emits light at a peak wavelength of 635nm with a viewing angle of 24 degrees.
The indicator features a clear, round lens with a domed top, measuring 5mm (T-1 3/4). The housing is black and UL 94 V-0 rated for high contrast and safety. The CBI (Circuit Board Indicator) design includes housing stand-offs to facilitate PCB cleaning.
This component is suitable for various board-level status indication applications where a reliable red LED indicator is required. Its through-hole mounting ensures a secure connection to the PCB.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage for the Dialight 5615501050 is 2.2V at 20mA.
The typical luminous intensity for the 5615501050 is 125mcd when operated at 20mA.
The peak wavelength for the Dialight 5615501050 is 635nm.
The typical viewing angle (2Θ½) for the 5615501050 is 24 degrees.
The Dialight 5615501050 is designed for through-hole mounting.
