| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Depth | |
| Height | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Rated Current | |
| Rated Voltage | |
| Specifications | |
| Standards | |
| Termination Style | |
| Thread | |
| Type | |
| Width | |
| Wire Gauge |
The Phoenix Contact 5602192 is a duplex GFCI outlet designed for use in the USA. It is rated for 125 V AC and 20 A. The device mounts on a 35 mm DIN rail per EN 60715. Screw terminal connections accept rigid conductors from 0.2 mm² to 6 mm² or flexible conductors from 0.2 mm² to 4 mm² (30 AWG to 10 AWG). Stripping length is 8 mm with M3 thread. The insulating material is PVC with a flammability rating of 94 V0. Operating temperature range is -20 °C to 50 °C. It complies with UL 508 and carries cULus Listing. Dimensions: 82 mm width, 135 mm height, 62 mm depth. White housing.
| Qty | Low | High |
|---|---|---|
| 1+ | $111.24 | $111.24 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
125 V AC
-20 °C to 50 °C
DIN Rail (35 mm rail per EN 60715)
RoHS3 Compliant (unverified)
