5451404 Phoenix Contact 5451404 is a 4-position plug connector with 5.08mm pitch, rated 12A and 320V, using screw termination for free hanging mounting.
Mfr Part #:

5451404

Available from 1 distributors
Mfr Name: Phoenix Contact
Phoenix Contact
Phoenix Contact 5451404 is a 4-position plug connector with 5.08mm pitch, rated 12A and 320V, using screw termination for free hanging mounting.
✓ Total Stock: 5 pcs

5451404 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Emiteli ✓
Non-Authorised Inventory information
5 pcs
On Request
5 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

5451404 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Current Rating
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Pitch
Plug Wire Entry
Positions Per Level
Termination Style
Type
Voltage
Wire Gauge or Range
View Similar Products (0)

5451404 Description

Short technical summary and product information.

The Phoenix Contact 5451404 (BCVP-508W-4 GN) is a 4-position plug connector from the BCVP-W series, designed for printed-circuit board applications. It features a 5.08mm pitch and uses screw connection for reliable wire termination. The plug is rated for a nominal current of 12A and a rated voltage of 320V (overvoltage category III/2), with a rated surge voltage of 4kV.



This component accepts solid or stranded conductors from 0.2 to 2.5 mm² (24-12 AWG) and requires a stripping length of 7mm. The screw thread is M3 with a tightening torque of 0.5-0.6 Nm. The insulating material is polyamide (PA) with a flammability rating of UL94 V0. The contact mating finish is tin.



The plug is free hanging (in-line) and has a 270° wire entry. It is available in pastel green color. The product is RoHS3 compliant and has an MSL of 1 (unlimited).

5451404 Quick Information

Product Type: Plug Connector
Series: BCVP-508W
Canonical Name: Phoenix Contact BCVP-508W-4 GN PCB Plug Connector
Subcategory: Headers, Plugs and Sockets

5451404 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 (Unlimited)
REACH Status: REACH Unaffected

5451404 Features

  • 4-position plug with 5.08mm pitch.
  • Rated 12A and 320V (III/2).
  • Screw termination for secure connections.
  • Accepts 0.2-2.5 mm² solid/stranded wire.
  • UL94 V0 polyamide insulation.

5451404 Applications

  • Used in PCB connector applications.
  • Suitable for industrial control systems.
  • Ideal for power distribution blocks.
  • Common in building automation wiring.

5451404 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the Phoenix Contact 5451404 have?

It has 4 positions.

What is the pitch of this plug connector?

The pitch is 5.08 mm.

What is the current rating of the 5451404?

The nominal current rating is 12 A.

What is the voltage rating of this connector?

The rated voltage is 320 V for overvoltage category III/2, 250 V for III/3, and 630 V for II/2.

What is the mounting type for this plug?

It is free hanging (in-line) mounting.
