| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Wire Gauge or Range |
The Phoenix Contact 5451394 is a 3-position plug component from the BCVP-508W series, designed for printed-circuit board connector applications. It features a screw connection with tension sleeve, providing reliable and secure wire termination.
Key electrical specifications include a nominal current of 12 A with a 2.5 mm² conductor cross section, and rated voltages of 250 V (III/3), 320 V (III/2), and 630 V (II/2). The insulating material is polyamide (PA) with a flammability rating of UL 94 V0.
Mechanically, the plug has a pitch of 5.08 mm, screw thread M3 with a tightening torque range of 0.5 to 0.6 Nm, and a stripping length of 7 mm. The contact mating finish is tin, and the housing color is pastel green. It accepts solid and flexible conductors from 0.2 mm² up to 2.5 mm² (24 AWG to 12 AWG).
The component is free hanging (in-line) and comes in a packing unit of 1 piece with a minimum order quantity of 100 pieces.
The rated voltage depends on overvoltage category: 250 V for III/3, 320 V for III/2, and 630 V for II/2.
It accepts solid and flexible conductors from 0.2 mm² to 2.5 mm², corresponding to 24 AWG to 12 AWG.
The pitch is 5.08 mm.
It is free hanging (in-line) and does not require mounting on a PCB.
The tightening torque range is 0.5 Nm minimum to 0.6 Nm maximum.
RoHS status is marked as RoHS3 compliant, though it has not been verified with an official certificate.
The insulating material is polyamide with a flammability rating of UL 94 V0.
