| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
170 pcs
|
170 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The 54202-T0807AB06LF is a rectangular header connector from Amphenol ICC, designed for board-to-board applications. It has 14 positions with 13 loaded, arranged in 2 rows with a pitch and row spacing of 2.54mm (0.100 inches). The contacts are male pins made of phosphor bronze with a tin finish of 100 microinches (2.54 micrometers). The contact length is 5.84mm (0.230 inches).
The insulation is black, with a height of 2.54mm, and is rated UL94 V-0 for flammability. The connector is unshrouded with a push-pull fastening type. It is surface mount with solder termination, and includes a pick-and-place feature for automated assembly. The current rating is 3A per contact, and the operating temperature range is -65°C to 130°C.
14 positions with 13 loaded.
2.54mm (0.100 inches).
3A per contact.
Surface mount with solder termination.
Phosphor bronze with tin finish (100 microinches).
-65°C to 130°C.
Yes, it features a pick-and-place feature for automated assembly.
