53611-S50-8 50-position surface mount header with male pins, 2.54mm pitch, shrouded 4-wall design, and latch lock/eject hooks. Suitable for board-to-cable/wire connections.
Mfr Part #:

53611-S50-8

Available from 1 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
50-position surface mount header with male pins, 2.54mm pitch, shrouded 4-wall design, and latch lock/eject hooks. Suitable for board-to-cable/wire connections.
✓ Total Stock: 125 pcs

53611-S50-8 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Hybrid Electronics ✓
Non-Authorised Inventory information
125 pcs
On Request
125 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

53611-S50-8 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Row Spacing
SVHC Present
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

53611-S50-8 Description

Short technical summary and product information.

The 53611-S50-8 is a 50-position, 2-row surface mount header manufactured by Amphenol ICC. It features male pin contacts made of phosphor bronze with a tin-lead finish (15.0µin thickness). The header is shrouded with a 4-wall design and includes a keying slot for proper alignment. A latch lock/eject hook fastening type ensures secure mating and easy disconnection. The insulation is black thermoplastic rated UL94 V-0 for flammability resistance, with an insulation height of 16.26mm. The pitch is 2.54mm and row spacing is also 2.54mm. Contact length is 5.84mm. Termination is via solder for surface mount assembly. This header is designed for board-to-cable/wire applications where a reliable, high-density interconnect is required. No electrical ratings are provided in the available data, so current and voltage capabilities should be verified with the manufacturer.

53611-S50-8 Quick Information

Product Type: Header, Male Pins
Canonical Name: CONN HEADER SMD 50POS 2.54MM
Subcategory: Headers, Male Pins

53611-S50-8 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

53611-S50-8 Features

  • 50-position, 2-row, 2.54mm pitch design.
  • Shrouded 4-wall housing with keying slot.
  • Latch lock/eject hooks for secure mating.
  • Surface mount solder termination.
  • UL94 V-0 rated thermoplastic insulation.

53611-S50-8 Applications

  • Board-to-cable/wire interconnection in industrial equipment.
  • Ideal for high-density pin count applications.
  • Used in applications requiring latch lock retention.
  • Suitable for surface mount assembly processes.

53611-S50-8 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does this header have?

50 positions.

What is the pitch of this header?

2.54mm (0.100").

What is the mounting type?

Surface mount (SMD).

What fastening type is used?

Latch lock/eject hooks.

What is the insulation material and flammability rating?

Thermoplastic with UL94 V-0 rating.

Is the header shrouded?

Yes, it has a shrouded 4-wall design.

What is the contact finish?

Tin-lead with a thickness of 15.0µin (0.38µm).
