Mfr Part #:

535542-8

Name: 535542-8
Brand: TE Connectivity
SKU: 535542-8

Mfr Name: TE Connectivity

Description:

CONN RCPT 16POS 0.1 GOLD PCB

Stock on Request

535542-8 Description

Short technical summary and product information.

CONN RCPT 16POS 0.1 GOLD PCB

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Headers, Receptacles, Female Sockets
Manufacturer Name	TE Connectivity
Connector Type	Receptacle, Bottom or Top Entry
Contact Finish	Tin-Lead
Contact Finish Thickness	30.0碌in (0.76碌m)
Contact Length	0.130" (3.30mm)
Contact Type	Female Socket
Current Rating (Amps)	2A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.265" (6.73mm)
Mounting Type	Through Hole
Number of Positions	16
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-65°C ~ 125°C
Pitch	0.100" (2.54mm)
Row Spacing	0.100" (2.54mm)
Style	Board to Board or Cable
Termination	Solder
