The RS PRO 534-878 is a yellow insulated female spade connector featuring a 6.35 x 0.8 mm tab size. It is designed for crimp termination and is suitable for wire gauges ranging from 12 AWG to 10 AWG (2.5 mm² to 6 mm²).
The connector body is constructed from brass with tin plating for reliable conductivity. The insulation is made of vinyl, offering a balance of economic value and suitability for general use. It has an overall length of 24 mm.
This spade connector operates at a maximum temperature of 75°C and a maximum voltage of 300V. The maximum current rating for the 12-10 AWG wire size is 24A. These connectors are versatile and can be used in various applications including machinery, electrical equipment, home appliances, automotive, and workshops.
Features include a piggyback disconnect design, providing an additional connection point. The double crimp type ensures a tighter connection by crimping down on both sides of the terminal.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The tab size is 6.35 x 0.8 mm.
This connector is designed for wire sizes from 12 AWG to 10 AWG, which corresponds to 2.5 mm² to 6 mm².
The maximum operating voltage is 300V and the maximum operating temperature is 75°C.
The maximum current rating for the 12-10 AWG wire size is 24A.
