| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,152 pcs
|
1152 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Finish | |
| Contact Material | |
| Features | |
| Halogen Free | |
| Insulation | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Operating Temperature Range | |
| Packaging Method | |
| Packaging Quantity | |
| Stud | |
| Stud Size | |
| Terminal Type | |
| Termination | |
| Tongue Thickness | |
| Voltage - Max | |
| Width | |
| Wire Gauge | |
| Wire Insulation Diameter (Minimum/Maximum) |
The TE Connectivity 52936 is a PIDG Short Spring Spade Tongue Terminal designed for 14-16 AWG wire. It features a spring spade tongue with a #8/M4 stud size and is fully insulated with a blue nylon sleeve. The terminal uses a crimp termination method and is made from tin-plated phosphor bronze for reliable electrical contact. It has a serrated termination for improved wire grip and strain relief. The operating temperature range is up to 105 °C and the maximum voltage rating is 300 V. The terminal is free hanging (in-line) and is packaged in tape-mounted format with 5000 pieces per reel. It is RoHS and REACH compliant and is low halogen.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.63 | $0.63 |
| 10+ | $0.53 | $0.53 |
| 25+ | $0.50 | $0.50 |
| 50+ | $0.48 | $0.48 |
| 100+ | $0.45 | $0.45 |
| 250+ | $0.42 | $0.42 |
| 500+ | $0.40 | $0.40 |
| 1,000+ | $0.38 | $0.38 |
| 3,000+ | $0.36 | $0.36 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
14-16 AWG (1.25-2 mm²).
#8 and M4 studs.
Yes, it is insulated with a blue nylon sleeve.
105 °C.
300 V.
Phosphor bronze contact with tin plating.
Crimp termination.
