| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
25 pcs
|
25 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Center Contact Material | |
| Connector Style | |
| Connector Type | |
| Contact Termination | |
| Fastening Type | |
| Frequency | |
| Halogen Free | |
| Housing Color | |
| Impedance | |
| Lead Style | |
| Mounting Feature | |
| Mounting Type | |
| Number of Ports | |
| Shield Termination | |
| Solder Process Capability |
The TE Connectivity 5227671-1 is a BNC jack connector designed for RF applications. It features a female socket contact and a straight body orientation. The connector offers a characteristic impedance of 50 Ohm and supports frequencies up to 4 GHz. It is panel mounted with a bulkhead front side nut and uses a bayonet lock fastening mechanism for secure connections. Both center and shield contacts are terminated via solder. The center contact is made of phosphor bronze, and the housing is silver. The connector is wave solder capable up to 265°C.
This component is compliant with EU RoHS Directive 2011/65/EU with exemption 6(c) for lead in copper alloy. It contains lead (up to 4% by weight) and is not lead-free. The halogen content is low (Br, Cl, F, I < 900 ppm per homogenous material) and it is BFR/CFR/PVC free. Under EU REACH, the part exceeds the SVHC threshold due to lead content (3.7% in component part). Moisture sensitivity level is MSL 1 (unlimited).
Designed for reliable performance in RF signal transmission, this connector is suitable for test and measurement equipment, telecommunications infrastructure, and broadcast video applications. The panel mount design allows for secure installation in enclosures. The bayonet lock provides quick connect and disconnect capability. Solder termination ensures robust electrical connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.35 | $5.35 |
| 10+ | $4.54 | $4.54 |
| 35+ | $4.16 | $4.16 |
| 70+ | $3.96 | $3.96 |
| 105+ | $3.85 | $3.85 |
| 280+ | $3.59 | $3.59 |
| 525+ | $3.44 | $3.44 |
| 1,015+ | $3.28 | $3.28 |
| 2,520+ | $3.08 | $3.08 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 Ohm.
4 GHz.
Panel mount with through hole, bulkhead front side nut.
Bayonet lock.
Solder.
Yes, compliant with exemptions (6(c) - Pb-Alloy in Copper).
Yes, contains lead in copper alloy up to 4% by weight.
