| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,608 pcs
|
3608 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Features | |
| Halogen Free | |
| Height Above Board | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Mated Stacking Heights | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch |
The TE Connectivity 5177984-1 is a plug connector part of the FH (0.80mm pitch) board-to-board connector series. It has 40 positions arranged in 2 rows with a 0.80mm pitch. The connector uses a plug with center strip contacts and is designed for surface mount soldering.
The housing is made of LCP (high temperature thermoplastic) with a UL 94V-0 flammability rating. Contacts are made of brass with a nickel underplate, gold plating in the engagement area, and matte-tin plating on the soldering area. The connector supports mated stacking heights of 5mm, 9mm, 13mm, and 17mm.
This part includes a board guide feature for alignment during assembly. It is rated as low halogen and has a moisture sensitivity level of 1 (unlimited). The component is packaged in tube format.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.64 | $3.64 |
| 22+ | $2.92 | $2.92 |
| 44+ | $2.78 | $2.78 |
| 66+ | $2.70 | $2.70 |
| 110+ | $2.61 | $2.61 |
| 264+ | $2.45 | $2.45 |
| 506+ | $2.34 | $2.34 |
| 1,012+ | $2.23 | $2.23 |
| 2,508+ | $2.09 | $2.09 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 40 positions arranged in 2 rows.
The pitch is 0.80mm.
Surface mount mounting.
Gold contact finish, with a thickness of 8.00µin (0.203µm) in the engagement area. The soldering area has a matte-tin finish.
The height above board is 4.60mm.
Supported mated stacking heights are 5mm, 9mm, 13mm, and 17mm.
The housing is made of LCP (high temperature thermoplastic) with a UL 94V-0 flammability rating.
