| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
36,353 pcs
|
36353 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The TE Connectivity 5176264-6 is a through-hole, unshrouded breakaway header designed for board-to-board or cable applications. It features 14 positions arranged in two rows with a 2.00mm (0.079") pitch. The square male pins are made of brass with a tin finish (0.76µm thickness) and an overall contact length of 8.10mm. The black thermoplastic insulator is rated UL94 V-0 for flammability. The push-pull fastening type and 4.00mm contact length make it suitable for general-purpose interconnects where a reliable solder connection is needed.
The connector supports operating temperatures from -40°C to 105°C and is rated for 200VAC. The insulation height is 1.50mm and row spacing matches the 2.00mm pitch. The component is designed for vertical mounting and all positions are loaded.
The pitch is 2.00mm (0.079").
The voltage rating is 200VAC.
Through hole with solder termination.
14 positions, all loaded, in 2 rows.
-40°C to 105°C.
Brass contacts with tin finish (0.76µm thickness).
Unshrouded breakaway header.
