| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
355 pcs
|
355 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The TE Connectivity 5102321-8 is a 34-position shrouded header designed for board-to-cable/wire applications. It features a 2.54mm pitch and 2 rows of male pins with tin-plated square contacts. The connector is fully shrouded with four walls, providing robust protection for the pins.
The header includes a keying slot and mounting flange for secure alignment and attachment to the PCB. The fastening type utilizes long latch lock/eject hooks for reliable mating retention. The insulation is black colored and rated UL94 V-0 for flammability.
Electrical ratings are 1A per contact and 250VAC. Operating temperature range spans from -65°C to 105°C. The contact length is 6.10mm with an overall contact length of 17.37mm. The through-hole termination type ensures robust soldering to the board.
| Qty | Low | High |
|---|---|---|
| 1+ | $10.21 | $10.21 |
| 24+ | $8.16 | $8.16 |
| 120+ | $7.28 | $7.28 |
| 504+ | $6.58 | $6.58 |
| 1,008+ | $6.27 | $6.27 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
34 positions in a 2-row configuration.
2.54mm (0.100 inches).
1A per contact.
250VAC.
Through hole solder termination.
-65°C to 105°C.
Tin, with a thickness of 30.0 microinches (0.76 micrometers).
