Mfr Part #:

5054483691

Name: 5054483691
Brand: Molex
SKU: 5054483691

Mfr Name: Molex

Description:

1.25WB DL RA ASSY 36CKT BK G010

Stock on Request

5054483691 Description

Short technical summary and product information.

1.25WB DL RA ASSY 36CKT BK G010

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Headers, Male Pins
Manufacturer Name	Molex
Connector Type	Header
Contact Finish	Gold
Contact Finish Thickness	3.94碌in (0.100碌m)
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	Varies by Wire Gauge
Fastening Type	Latch Holder
Features	Pick and Place, Solder Retention
Insulation Color	Black
Insulation Height	0.352" (8.95mm)
Insulation Material	Polyamide (PA), Nylon
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount, Right Angle
Number of Positions	36
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-40°C ~ 105°C
Pitch	0.049" (1.25mm)
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	50VAC/DC
