| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
250 pcs
|
250 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Capacitance | |
| Features | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Thickness (Max) | |
| Tolerance | |
| Voltage | |
| Width |
The 501S47W474KV4E is a surface mount multilayer ceramic capacitor (MLCC) manufactured by Johanson Dielectrics. It offers a capacitance of 0.47 µF with a voltage rating of 500V DC. The capacitor uses X7R dielectric, providing a temperature coefficient that ensures stable capacitance over a range of -55°C to 125°C with a tolerance of ±10%.
This component is housed in a 2220 (5750 Metric) package with dimensions of 5.72mm length, 5.08mm width, and a maximum thickness of 3.81mm. It is designed for surface mount assembly and is suitable for general purpose applications requiring high voltage handling. The high voltage feature makes it appropriate for power supply decoupling, DC blocking, and snubber circuits.
The operating temperature range of -55°C to 125°C allows use in a variety of environments. The part is marked as RoHS3 compliant and REACH unaffected, though these compliance claims are unverified. No pricing or stock data is available from distributors.
0.47 µF.
500V DC.
X7R.
±10%.
2220 (5750 Metric).
-55°C to 125°C.
Surface Mount, MLCC.
