| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | 1970-01-01 00:33:51 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Locking Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Molex 5019515030 is a 50-position, 0.5mm pitch FFC/FPC connector in a vertical surface mount package. It is designed for flat flexible cables and flexible printed circuits, supporting both straight and tapered cable end types. The connector features a flip lock actuator for secure cable retention and gold-plated phosphor bronze contacts for reliable electrical performance. The housing is made of liquid crystal polymer (LCP) with glass filling, rated UL94 V-0 for flammability. The operating temperature range is -40°C to 85°C, and the voltage rating is 50V. The connector includes a solder retention feature to aid in board assembly. It accommodates FFC/FPC thickness of 0.30mm. This connector is suitable for high-density interconnection applications where space is constrained.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.70 | $2.70 |
| 10+ | $2.30 | $2.30 |
| 25+ | $2.05 | $2.05 |
| 100+ | $1.96 | $1.96 |
| 250+ | $1.83 | $1.83 |
| 500+ | $1.75 | $1.75 |
| 1,000+ | $1.72 | $1.72 |
| 2,000+ | $1.67 | $1.67 |
| 4,000+ | $1.60 | $1.60 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50
0.5mm
50V
Surface mount
Gold
-40°C to 85°C
Flip lock
