| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,270 pcs
|
1270 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The 5-826631-0 is a 50-position, single-row, unshrouded male pin header manufactured by TE Connectivity. It features a 2.54mm (0.100") pitch and a right-angle through-hole mounting style, making it suitable for board-to-board or cable connections. The header is constructed with a green PBT (Polybutylene Terephthalate) insulator rated UL94 V-0 for flammability, and brass contacts with a tin finish (3.90µin thickness). Each contact is rated for 5A current, and the operating temperature range spans -65°C to 105°C. The push-pull fastening type and solder termination simplify assembly. Compliance includes RoHS3, REACH unaffected, and MSL 1 (unlimited). This part is commonly used in industrial control, computing, and telecommunications equipment where a reliable right-angle connection is required.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.01 | $6.01 |
| 10+ | $5.11 | $5.11 |
| 100+ | $5.05 | $5.05 |
| 250+ | $4.06 | $4.06 |
| 500+ | $3.87 | $3.87 |
| 1,000+ | $3.59 | $3.59 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 50 positions, all loaded.
The pitch is 2.54mm (0.100").
Each contact is rated for 5A.
Through hole, right angle.
-65°C to 105°C.
The insulator is made of PBT with a UL94 V-0 flammability rating.
The part is listed as RoHS3 compliant, though this is unverified. It is recommended to verify with the manufacturer.
